Belt conveyor
PVC or PU belt on a mild-steel or stainless frame; the general-purpose choice for pouches, bags, bottles and trays
Material Handling · Conveyors
Industrial Conveyor System Malaysia
Chain, roller, accumulation and inclined belt conveyors, engineered as one material-handling network for packaging, sorting and palletizing lines across Malaysia.
Chain, roller, belt, accumulation
Custom layouts
Fabricated and installed locally
Conveyor SystemFull specs
Overview
Conveyor system Malaysia: chain, roller, belt and accumulation
Welpack designs and fabricates every conveyor system Malaysia manufacturers need to move product between machines: chain conveyors for heavy loads, roller conveyors for cartons and cases, accumulation conveyors that buffer product ahead of a slower machine, and inclined or vertical belt conveyors that change level. Each line is engineered for the load, the layout and the installation conditions on your floor, then built in our Puchong workshop and installed on site.
Integrated with filling, coding, inspection, case packing and palletizing equipment, the conveyors become one material-handling network. Product flows continuously from the first machine to the pallet, with fewer manual transfers, fewer stoppages and a line speed that is set by the fastest machine rather than by the people carrying boxes between them.
Types
Which conveyor for which job
Frame material, belt or roller type and drive are chosen per section of the line. Full datasheet on request.
Conveyor types at a glance
Roller conveyor
Gravity or powered rollers for cartons, cases and shrink packs; low cost per metre and easy to extend
Chain conveyor
Steel or stainless chain for pallets, drums, crates and other heavy or awkward loads
Accumulation conveyor
Zero-pressure zones that buffer product when a downstream machine pauses, so upstream machines keep running
Modular belt conveyor
Interlocking plastic modules for curves, inclines and wash-down areas; hygienic and easy to replace section by section
Incline and vertical conveyor
Cleated belts and vertical lifts that move product between floor level, mezzanines and elevated machine infeeds
Stainless steel conveyor
SS304 frames and food-grade belts for food, beverage and pharmaceutical lines that are washed down
Frame and finish
Mild steel powder-coated, stainless steel or aluminium, fabricated in-house in Puchong
Every Welpack conveyor
Layout drawn around your existing machines and floor space
Speed matched to the fastest machine on the line
Guide rails, side guards and transfers built to your product
Variable-speed drives on powered sections
Spare belts, rollers and chain stocked in Malaysia
Installed and commissioned by our own technicians
Guide
Conveyor system Malaysia: four questions we ask before quoting
What is the product? A sealed pouch, a glass bottle, a shrink-wrapped tray and a 25 kg bag each need a different surface, width and side guide. The product decides whether a belt, roller, chain or modular conveyor is the right section, and whether it needs cleats, flights or a flat top.
How fast does the line run? The conveyor is sized to the output of the fastest machine it feeds, with an accumulation zone wherever a machine downstream is slower or stops for changeovers. Under-sizing a conveyor is the most common reason a new packing machine never reaches its rated speed.
What does the floor look like? Columns, doorways, mezzanines and existing machines fix the route. We survey the floor, draw the layout with the transfers, curves and inclines it needs, and confirm it with you before anything is cut.
What is the environment? Dry cartons in a warehouse can run on powder-coated mild steel. Food, beverage and pharmaceutical lines that are washed down need stainless steel frames, food-grade belts and open designs that can be cleaned. The same conveyor machine Malaysia food plants use is built differently from the one that moves boxes in a logistics hub.
How we work
From site survey to running line
Every conveyor system Malaysia customers order from us is a project, not a catalogue item. This is the sequence.
1
Site survey
We measure the floor, the machines already in place and the product you run, and agree the throughput the line must reach.
2
Layout and quotation
A layout drawing with each conveyor section, its type, length and drive, plus a quotation, usually within two working days of the survey.
3
Fabrication in Puchong
Frames, guards and transfers are cut, welded and finished in our own workshop, so changes during the build do not wait on a supplier.
4
Installation and commissioning
Our technicians install, align and run the line with your product, train your operators and hand over with spares on the shelf.
Industries
Where our conveyor machines run in Malaysia
Every conveyor machine Malaysia customers order from Welpack is fabricated in Puchong and installed on site, from single-section transfers to full-floor networks.
Food & Beverage
Vertical conveyors move packaged goods such as cans, bottles or trays up to mezzanine levels, while belt and roller conveyors carry items through filling, sorting and packing stations.
Logistics & E-commerce
Roller and accumulation conveyors sort, buffer and dispatch parcels in warehouses and distribution centres, and vertical lifts link floors or mezzanines in high-density storage.
Pharmaceuticals & Healthcare
Material handling systems carry sterile packaging, labelled bottles or blister packs. Vertical conveyors move items between production levels with minimal contamination risk.
FMCG & Consumer Goods
High-throughput consumer goods lines use conveyor systems to carry bottles and tubes through packaging and palletizing without manual handling.
Manufacturing & Assembly
Vertical and belt conveyors carry components, sub-assemblies and finished products between workstations, floors and storage in production plants.
Scope
What a Welpack conveyor project includes
One supplier for the mechanical, electrical and after-sales side of the line.
Conveyor frames, belts, rollers and chain fabricated to the layout
Drives, motors and variable-speed control on powered sections
Guide rails, side guards, product stops and transfers
Curves, merges, diverts and 90-degree transfers between sections
Integration with filling, sealing, coding, checkweigher and palletizer infeeds
Installation, alignment and commissioning with your product
Operator training and a recommended spares list
Replacement belts, rollers, chain and sprockets stocked in Malaysia
FAQ
Common questions
Which conveyor system Malaysia manufacturers choose for a packaging line?
Most packaging lines combine several types: a belt conveyor at the filling and sealing machines, an accumulation conveyor before the case packer, roller conveyors for finished cases and a chain conveyor or vertical lift at the palletizer. We specify each section separately and join them into one line.
Is every conveyor machine Malaysia-made, or imported?
We fabricate frames, guards and transfers in our own workshop in Puchong, Selangor. Belts, rollers, chain, motors and drives are sourced from standard suppliers so spares are available locally. Because the fabrication is ours, a conveyor can be built to an unusual layout or product without waiting on an overseas factory.
Can a conveyor connect to machines from other brands?
Yes. The conveyor is built to the infeed and outfeed heights of the machines already on your floor, whether they are Welpack machines or another brand. We measure them during the site survey.
How long does a conveyor project take?
A single straight section can be built and installed within weeks. A full line with accumulation, inclines and palletizer infeed is a project: the layout is agreed first, then fabrication, then installation on a date that suits your production. We give the timeline with the quotation.
What about stainless steel and wash-down lines?
For food, beverage and pharmaceutical plants we build stainless steel conveyors with food-grade belts or modular belts, open frames and sealed bearings so the line can be washed down. Tell us the cleaning regime and we specify the materials to suit.
Do you supply replacement belts, rollers and chain?
Yes. PU and PVC belts, rollers, stainless steel chain, sprockets and bearings are stocked in Malaysia for Welpack conveyors and for many other makes. See our conveyor parts and components page or send us a photo of the worn part.
Related machines
Build the rest of the line
The two specialised conveyor pages, and the machine most often fed by one.
Packaging Conveyor Systems
Belt, roller and modular conveyors that carry bottles, cartons, trays and packs between filling, coding, inspection and palletizing.
View machine Vertical Conveyor Systems
Moves cartons, trays and packs between floor levels and mezzanines in a compact footprint.
View machine Robotic Palletizer
A robotic arm that picks cases, bags or trays off the conveyor and stacks them on the pallet in a programmed pattern.
View machine Tell us your product, line speed and floor plan
We draw the layout and quote, usually within 2 working days.
